Ubiquiti WiFi 6E in-wall access point with 2.5GbE input, four GbE outputs, 6 GHz support, up to 4.8 Gbps per 5/6 GHz band, PoE+, and support for 600+ concurrent clients.
PRODUCT TYPE
Wireless Access Points
KEY FEATURES
• WiFi 6E with 2.4 GHz, 5 GHz, and 6 GHz operation • (1) 2.5GbE RJ45 data input • (4) GbE RJ45 data outputs • (1) PoE+ input and (1) PoE output • PoE+ powered • PoE++ required to enable PoE output • 4×4 DL/UL MU-MIMO at 5 GHz • 4×4 DL/UL MU-MIMO at 6 GHz • Up to 4.8 Gbps throughput at 5 GHz • Up to 4.8 Gbps throughput at 6 GHz • Supports 600+ concurrent clients • Zero-wait DFS supported • 802.1Q VLAN support • Guest traffic isolation • Ethernet and Bluetooth management
TECHNICAL SPECIFICATIONS
• Manufacturer: Ubiquiti • Model / Part Number: U6-Enterprise-IW • Dimensions: 159.7 x 156.7 x 33.8 mm (6.3 x 6.2 x 1.3″) • Weight: 884 g (1.9 lb) • Enclosure Materials: Polycarbonate, Aluminum • Mount Material: Aluminum • Data Input: (1) 2.5GbE RJ45 Port • Data Outputs: (4) GbE RJ45 Ports • Management Interface: Ethernet, Bluetooth • PoE Interface: (1) PoE+ In, (1) PoE Out • Power Method: PoE+ • PoE++: Required for PoE Output • Power Supply: UniFi PoE Switch • Maximum Power Consumption: 21 W, Excluding PoE Output • Maximum PoE Wattage Per Port by PSE: 15.4 W • Supported Voltage Range: 44–57V DC • Maximum TX Power at 2.4 GHz: 22 dBm • Maximum TX Power at 5–7 GHz: 26 dBm • 2.4 GHz MIMO: 2×2 UL MU-MIMO • 5 GHz MIMO: 4×4 DL/UL MU-MIMO • 6 GHz MIMO: 4×4 DL/UL MU-MIMO • 2.4 GHz Throughput Rate: 573.5 Mbps • 5 GHz Throughput Rate: 4.8 Gbps • 6 GHz Throughput Rate: 4.8 Gbps • 2.4 GHz Antenna Gain: 4 dBi • 5 GHz Antenna Gain: 5.8 dBi • 6 GHz Antenna Gain: 5.8 dBi • WiFi Standards: 802.11a/b/g, WiFi 4, WiFi 5, WiFi 6, WiFi 6E • Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) • BSSID: 8 Per Radio • VLAN: 802.1Q • Advanced QoS: Per-User Rate Limiting • Guest Traffic Isolation: Supported • Concurrent Client Support: 600+ • Zero-Wait DFS: Yes • Operating Temperature: -30 to 60°C (-22 to 140°F) • Operating Humidity: 5 to 95% Noncondensing • Certifications: CE, FCC, IC
Specifications
