Ubiquiti UISP Cable Pro CAT5e 1000ft Shielded Ethernet Cable

Description

UISP Cable Pro – Shielded CAT5e Ethernet Cable for Outdoor Use

The Ubiquiti UISP Cable Pro is a high-quality, shielded Ethernet cable designed for industrial and outdoor installations. With a length of 305 meters (1,000 feet), this black, UV-resistant cable ensures stable, high-performance connectivity in various environments. It supports Ethernet speeds up to 1 Gbps, making it ideal for demanding applications. The solid bare copper conductors, robust insulation, and protective jacket offer long-lasting durability and protection against external factors like UV exposure and harsh weather conditions.

Key Features:

• UV-resistant for long-term outdoor use
• Supports Ethernet speeds up to 1 Gbps
• Shielded CAT5e construction with solid bare copper conductors
• Includes a rip cord for easy cable installation
• Operates in extreme temperature conditions

Technical Specifications:

Box Dimensions: 330 x 330 x 340 mm (13 x 13 x 13.4″)
Box Weight: 12 kg (26.5 lb)
Cable Length: 305 m (1,000 ft)
Cable Color: Black
Cable Type: CAT5e, shielded
UV Resistance: ASTM G 151/154
Ethernet Support: Up to 1 Gbps
Conductor Wire Gauge: 24 AWG
Conductor: Solid bare copper
Conductor Diameter: 0.500 ± 0.005 mm
Insulation Type: Solid polyethylene
Insulation Thickness: Avg. 0.26 mm (Min. 0.25 mm)
Insulation Diameter: 1.04 ± 0.03 mm
Separation (Polyester Wrapping): 0.025 mm thick, Extent: 20 mm
Cable Shield (Aluminum Foil): 0.060 mm thick, Extent: 18 mm
ESD Drain Wire: 0.4 CCS
Rip Cord: Yes
Jacket Material: Polyethylene
Jacket Thickness: Avg. 0.50 mm (Min. 0.46 mm)
Jacket Outer Diameter: 6.0 ± 0.30 mm
Jacket Color: Black
Storage Temperature: -30 to 75° C (-22 to 167° F)
Installation Temperature: -20 to 60° C (-4 to 140° F)
Ambient Operating Temperature: -40 to 80° C (-40 to 176° F)
Standards: ANSI/TIA-568-C.2 (2009), ISO/IEC 11801 (Edition 2.2)
