Ubiquiti UniFi AC In-Wall Access Point (UAP-AC-IW)
The Ubiquiti UniFi AC In-Wall Access Point (UAP-AC-IW) offers seamless Wi-Fi coverage and high-performance connectivity in an elegant in-wall design. It supports advanced features for businesses and homes, with support for Wi-Fi 5 (802.11ac) and maximum data rates of 450 Mbps on 2.4 GHz and 867 Mbps on 5 GHz. The UAP-AC-IW is designed to integrate easily with your existing network, offering PoE power via Ethernet for easy installation. Its sleek design allows for wall or ceiling mounting, providing coverage in high-density environments.
Key Features:
Elegant in-wall design for discrete placement
Supports Wi-Fi 5 (802.11ac) with dual-band performance
Max data rate of 450 Mbps on 2.4 GHz, 867 Mbps on 5 GHz
Ideal for high-density environments with support for 250+ clients
Power over Ethernet (PoE) for easy installation
Technical Specifications:
Dimensions: Ø175.7 x 43.2 mm (Ø6.9 x 1.7″) Weight: Without mount: 240 g (8.5 oz); With mount: 315 g (11.1 oz)
Networking interface: (1) GbE RJ45 port Management interface: Ethernet Power method: PoE, Passive PoE (24V) Power supply: UniFi PoE switch, 24V, 0.5A Gigabit PoE adapter (5-packs do not include PoE adapters) Max. power consumption: 6.5W Max. TX power
2.4 GHz: 24 dBm
5 GHz: 22 dBm MIMO
2.4 GHz: 3 x 3 (DL MU-MIMO)
5 GHz: 2 x 2 (DL MU-MIMO) Max. data rate
2.4 GHz: 450 Mbps (BW40)
5 GHz: 867 Mbps (BW80) Antenna gain
2.4 GHz: 3 dBi
5 GHz: 3 dBi Button: Factory reset Mounting: Wall, ceiling (Included) Ambient operating temperature: -10 to 70° C (14 to 158° F) Ambient operating humidity: 5 to 95% noncondensing Certifications: CE, FCC, IC
Software:
Wi-Fi standards: 802.11 a/b/g/n/r/k/v/ac
Wireless security: WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
BSSID: Up to 8 per radio
VLAN: 802.1Q
Advanced QoS: Per-user rate limiting
Guest traffic isolation: Supported
Power save: Supported
WMM: Voice, video, best effort, and background
Concurrent clients: 250+
Supported Data Rates (Mbps):
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40)
802.11ac: 6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
