Description
Ubiquiti UniFi Switch Ultra 60W – Compact 8-Port GbE PoE Switch
The Ubiquiti UniFi Switch Ultra 60W (USW-Ultra-60W) offers high-performance Layer 2 switching with eight GbE PoE+ ports and a compact design. Featuring versatile power options and efficient PoE distribution, this switch is perfect for small office and home networks, providing up to 42W of PoE availability. With its included power adapter and rugged polycarbonate enclosure, it ensures durability and reliability while maintaining a small footprint for flexible deployment in various settings.
Key Features:
- 8 GbE PoE+ output ports with flexible power options
- Compact design for easy deployment in various environments
- Supports up to 42W PoE availability via included 60W adapter
- Efficient switching with 16 Gbps switching capacity
Technical Specifications:
Dimensions: 203 x 76 x 33 mm (8 x 3 x 1.3″)
Weight: Device: 320 g (11.3 oz)
Weight: Wall mount: 45 g (1.6 oz)
Weight: 60W AC Adapter: 330 g (11.6 oz)
Enclosure Material: Polycarbonate
Management Interface: Ethernet In-Band
Networking Interface: (8) GbE RJ45 ports
PoE Interface: (7) PoE/PoE+ (Pins 1, 2+; 3, 6-), (1) PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 😎
Total Non-Blocking Throughput: 8 Gbps
Switching Capacity: 16 Gbps
Forwarding Rate: 11.904 Mpps
Power Method: (1) 54V, 1.1A power adapter (Included)
Power Supply: 54V, external, 1.1A/60W
Supported Voltage Range: 44—57V DC
Max. Power Consumption: 9W with PoE input (Excluding PoE output), 8W with AC adapter input (Excluding PoE output)
Total Available PoE: PoE++ input: 42W, PoE+ input: 16W
Max. PoE+ Wattage Per Port by PSE: 30W
Button: Factory reset
Ambient Operating Temperature: PoE++ input: -30 to 60° C (-22 to 140° F), 60W AC adapter input: -20 to 45° C (-4 to 113° F)
Ambient Operating Humidity: 10 to 90% noncondensing
Certifications: CE, FCC, IC
Switching Features:
- STP / RSTP with priorities and port-level disable
- Port isolation
- Storm control, Port mirroring
- Multicast / broadcast rate limiting, Flow control
- Jumbo frames, Egress rate limit
Application Requirements:
UniFi Network Version 8.0.7 and later
